Connecting adapter 1" / 28 mm – external thread 1" for Split plus wall-hung module (2 pcs)
Code: 0010039178Related products
Product detailed description
Connecting adapter 1" / 28 mm – external thread, pack of 2 pieces, for the Split plus hanging module.
The Vaillant uniTOWER system (in the plus and Split plus versions) is a compact hydraulic module in the shape of a tower with a footprint comparable to a standard refrigerator, which in one housing combines a hot water tank with a volume of 190 l, a complete heating hydraulic system, a backup electric heater, and a control unit. The module is connected in the aroTHERM / aroTHERM plus / aroTHERM Split system to an external (or internal, in the Split version) air-to-water heat pump unit and is responsible for distributing heat to the heating circuit and preparing hot water. That is why, since most components are integrated directly in the tower body, Vaillant offers a range of supplementary, connecting, and service parts for the module, which allow the hydraulics to be adapted to a specific installation – ceiling height, connection side, hot water circulation needs, or additional hydraulic separation of circuits.
Heat pump aroTHERM and the location of the part in the system
Heat pumps of the aroTHERM / aroTHERM plus / aroTHERM Split range extract heat from the air even at low outdoor temperatures and transfer it to the heating circuit and hot water tank via the uniTOWER module. Since, compared to a gas boiler, lower hot water temperatures are used and there is a greater emphasis on the correct hydraulic balancing of the entire circuit, the quality and compatibility of each individual hydraulic component – including expansion tanks, circulation and connecting kits – are directly linked to the overall efficiency and quiet operation of the system. The use of non-original or incorrectly dimensioned parts can negatively affect both the hydraulic balance and the declared performance coefficient (COP) of the system.
Composition of the delivery and packaging
The part is delivered in the original Vaillant packaging, which protects the connecting threads and sealing surfaces from damage during transport. The delivery always includes the necessary assembly documentation (installation instructions) in a language supported by the manufacturer, based on which the service technician will verify the correct sequence of assembly steps, tightening torques of connections, and the method of checking the tightness after connection.
Lifespan, service, and preventive maintenance
The hydraulic components of the uniTOWER module are designed for long-term maintenance-free operation. Nevertheless, we recommend checking the condition of this part – especially the tightness of the connections, possible signs of corrosion or medium leakage, and the functionality of the associated valves – during the regular annual service inspection of the heat pump. Early preventive checks extend the lifespan of the entire system and reduce the risk of unplanned heating or hot water preparation outages, especially during the winter period.
What the adapter is used for
This is a similar type of reducing adapter as the part with code 0010038385, but in a different version – with an external thread of 1" instead of a nut. The adapter allows the connection of the inch (threaded) connection of the hanging module uniTOWER Split plus to a pipe with an outer diameter of 28 mm. The choice between the version with an internal and external thread depends on the type of mating part to which the adapter is connected (e.g., a closing valve with an internal thread requires an adapter with an external thread, and vice versa).
Technical parameters
- Type: connecting (reducing) adapter
- Dimensions: 1" / 28 mm
- Version: external thread on the 1" side
- Packaging: 2 pieces
- Application: connecting the hanging module uniTOWER Split plus to a pipe with an outer diameter of 28 mm
How to choose the correct version (nut vs. external thread)
When ordering this type of adapter, it is essential to know the type of thread on the mating part (valve, fitting, or other connecting element) to which the adapter is connected – if the mating part has an internal (nut) thread, you need an adapter with an external thread (this part), and vice versa, if the mating part has an external thread, the version with a nut is required (code 0010038385). In case of doubts, we recommend consulting with an installation technician or sending a photograph of the existing connection.
Installation and assembly
The part is intended for installation into the body of the uniTOWER module and its installation must be carried out only by a trained service technician authorized by Vaillant. An incorrectly installed or improperly assembled hydraulic circuit can cause leaks, reduced system efficiency, or void the warranty on the entire device. Therefore, we recommend having the project documentation available or at least a photograph of the actual installation condition and the exact type of the uniTOWER module (including the performance range and plus/Split plus version), because individual connecting kits differ in side version and type of sealing.
Related accessories for the uniTOWER module
- Expansion tank 8 l for hot water (TÚV) (code 0020170500)
- Set with TV circulation pump (code 0020170503)
- Set with TV circulation pump for Split plus (code 0010038384)
- Circulation connecting set without pump (code 0010042664)
- Make-up set (code 0010038388)
- Make-up set with thermostatic mixing valve (code 0010038386)
- Non-insulated connecting set (low ceilings, right) (code 0010039993)
- Insulated connecting set (low ceilings, right) (code 8000012566)
- Insulated connecting set (low ceilings, left) (code 8000012577)
- Insulation covers for connecting valves (2 pcs) (code 0010042662)
- Connecting adapter 1" / 28 mm – nut (2 pcs) (code 0010038385)
- Hydraulic separation module for uniTOWER /7 (code 0010039991)
- Expansion tank 2 l for separation module /7 (code 0010040112)
- Internal unit connection Presfitting (code 0010027979)
Frequently asked questions
Is this adapter interchangeable with code 0010038385?
No directly – these are mutually complementary (not interchangeable) parts with opposite types of threads, the choice depends on the specific mating part on the distribution side.
Is this adapter intended only for the hanging (wall-mounted) version of the module?
Yes, according to the manufacturer's designation, this specific variant is intended for the hanging module uniTOWER Split plus.
Does the packaging include a gasket?
Yes, the adapter is delivered with the appropriate gasket ensuring the tightness of the connection.
Why order this part at atria.sk
We are a specialized e-shop focused on heating technology, heat pumps, and related accessories, including less common service and supplementary parts that are not available in regular hobby stores. By ordering from us, you are assured that it is an original Vaillant part delivered through an authorized distributor, not an unverified replacement from an unclear source. For larger orders of related accessories (e.g., a complete connecting kit together with an expansion tank and a make-up set), we are happy to prepare a joint offer and recommendation based on the type of your specific uniTOWER module.
Our sales representatives are in regular contact with service technicians and installation companies that actually carry out the installation of uniTOWER modules and aroTHERM heat pumps in the field – thanks to this, we can choose the correct part not only based on catalog data, but also on practical experience with specific types of connections. If you are unsure which exact variant of the part (e.g., connection side, insulated or non-insulated version) your system requires, do not hesitate to contact us before placing your order – this will help you avoid possible exchange or return of the goods.
Warranty, supplier, and support
We provide a 2-year warranty on this original Vaillant part. The product is delivered by an authorized Vaillant partner for the Slovak market, the company WINTNER s.r.o., which ensures the authenticity of the part and its full compatibility with other system components of the uniTOWER system. When ordering, we recommend specifying the exact designation and side version of the installed uniTOWER module (type, performance range, plus / Split plus version), so that we can verify 100% compatibility of the part before shipment. In case of uncertainties regarding the selection of the correct part or planning the installation, we are happy to advise you by phone or email – contact our sales department before ordering if you are unsure about the compatibility with your specific model.
Kondenzačný kotol
Kondenzačné kotly sú výkonné a úsporné zdroje tepla, ktoré využívajú kondenzačný efekt výparov spalín. Tým sa zvyšuje účinnosť a znížia sa emisie CO2.
Technické vlastnosti
Tento kondenzačný kotol je vybavený pokročilým regulátorom teploty a automatickým systémom čistenia. Je vhodný pre rodinné domy aj menšie komerčné objekty.
Additional parameters
| Category: | Heat Pump Accessories |
|---|---|
| Warranty: | 2 years |
| Weight: | 0.8 kg |
| Category: | Connecting adapter |
| Dimensions: | 1" / 28 mm, external thread |
| Number of pieces: | 2 |
