Baxi Luna3 Comfort AIR 250 Fi

Product detailed description

Output: 9,3 – 25 kW, combi with DHW, forced flue gas discharge (turbo) - Baxi  Luna3 Comfort AIR 250 Fi

The boiler includes a panel that, via a special receiving unit (interface) built into the front of the boiler, allows wireless control and programming of the heating and DHW modes. Once an outdoor temperature sensor is connected, it acts as a programmer for the built-in weather compensation control. This control panel is included in the price of the boiler.

Hydraulic system

•    Electric three-way valve (1)
• Steel burner
• Primary copper heat exchanger with a corrosion-resistant alloy coating
• Secondary stainless steel heat exchanger
• Automatic bypass
• Low-consumption circulation pump with a built-in air vent
• Anti-seizing function for the pump and three-way valve, activating every 24 hours
• Heating circuit safety valve, 3 bar

Heating control

• Two heating water temperature control ranges: 30/85°C, 30/45°C
• Built-in weather compensation control (activated once an outdoor sensor, available as an optional accessory, is connected)
• Room thermostat and programming timer for 2 heating levels, included in the control panel

Control and safety features

• Primary heat exchanger overheat safety thermostat
• Hydraulic pressure switch that shuts off the gas supply in case of insufficient water
• Safety pressure switch for checking correct flue gas discharge (Fi models)
• Pressure gauge for the heating circuit
• Anti-freeze function
• Electronic thermometer

General parameters:

		Heating + DHW
		turbo
Model		LUNA3 COMFORT AIR 250 Fi	LUNA3 COMFORT AIR 250 Fi
Suitable for cascade connection
Rated heat output	(kW)	25	31
Reduced heat output	(kW)	9,3	10,4
Minimum DHW flow rate	(l/min)	2	2
DHW output at a 25°C rise	(l/min)	14,3	17,8
DHW output at a 35°C rise	(l/min)	10,2	12,7
Specific DHW flow rate	(l/min)	11,5	13,7
Coaxial flue diameter	(mm)	100/60	100/60
Twin-pipe flue diameter	(mm)	80	80
Electric three-way valve		No	No
Electrical voltage / frequency	(V/Hz)	230/50	230/50
Rated electrical input	(W)	135	165
Weight	(kg)	38	40
Dimensions
Height	(mm)	763	763
Width	(mm)	450	450
Depth	(mm)	345	345
