Baxi Luna3 Comfort Max 240 i
Code: CSB453243580Product detailed description
Power range from 24 to 31 kW
- Expansion vessel with a built-in accumulation tank (patented Baxi system)
- Larger stainless steel heat exchanger
- Removable control panel with central heating-control function, LCD display and buttons for programming and adjustment
- Once an outdoor sensor (available to order) is connected, advanced weather compensation control is available directly from the boiler's control unit
- DHW output (ΔT 25°C): up to 18 l/min
- Easy installation thanks to the connection kit included in the delivery
Hydraulic system
- Electric three-way valve
- Steel burner
- Primary copper heat exchanger with a corrosion-resistant alloy coating
- Automatic bypass
- Low-consumption circulation pump with adjustable speed and a built-in air vent
- Anti-seizing function for the pump and three-way valve, activating every 24 hours
- Heating circuit safety valve, 3 bar
Heating control
- Two heating water temperature control ranges: 30/85°C, 30/45°C
- Built-in weather compensation control (activated once an outdoor sensor, available as an optional accessory, is connected)
- Room thermostat and programming timer for 2 heating levels, included in the control panel
Control and safety features
- Primary heat exchanger overheat safety thermostat
- Temperature control via NTC sensors
- Hydraulic pressure switch that shuts off the gas supply in case of insufficient water
- Safety pressure switch for checking correct flue gas discharge (Fi models)
- Safety thermostat for checking correct flue gas discharge (i models)
- Anti-freeze function
- Electronic thermometer
- Pressure gauge for the heating circuit
- Patented AFR air control system for optimising efficiency (Fi models with a split flue duct
General parameters:
| Heating + DHW | ||||
| turbo | chimney | |||
| Model | LUNA3 COMFORT MAX 250 Fi | LUNA3 COMFORT MAX 310 Fi | LUNA3 COMFORT MAX 240 i | |
| Suitable for cascade connection |  |
|
|
|
| Rated heat output | (kW) | 25 | 25 | 24 |
| Reduced heat output | (kW) | 9,3 | 9,3 | 9,3 |
| Heating water temperature control range | (°C) | 30/85 - 30/45 | 30-/85 - 30/45 | 30/85 - 30/45 |
| DHW temperature control range | (°C) | 35/60 | 35/60 | 35/60 |
| Minimum DHW flow rate | (l/min) | - | 2 | 2 |
| DHW output at a 25°C rise | (l/min) | 14,3 | 17,8 | 13,7 |
| DHW output at a 35°C rise | (l/min) | 10,2 | 12,7 | 9,8 |
| Specific DHW flow rate | (l/min) | 11,5 | 13,7 | 10,7 |
| Coaxial flue diameter | (mm) | 100/60 | 100/60 | - |
| Twin-pipe flue diameter | (mm) | 80/80 | 80/80 | - |
| Flue diameter (chimney) | (mm) | - | - | 120 |
| Electric three-way valve | No | No | No | |
| Electrical voltage / frequency | (V/Hz) | 230/50 | 230/50 | 230/50 |
| Rated electrical input | (W) | 135 | 165 | 80 |
| Weight | (kg) | 38 | 40 | 33 |
| Dimensions | ||||
| Height | (mm) | 763 | 763 | 763 |
| Width | (mm) | 450 | 450 | 450 |
| Depth | (mm) | 345 | 345 | 345 |
Additional parameters
| Category: | Baxi |
|---|---|
| Warranty: | 2 years |
| Product replaced by new one: | https://www.atria.sk/protherm-gepard-condens-18-25-mkv-thermolink-p/ |
| The item has been sold out… | |
