Electronic Circulation Pump NOVA MAX 50-120/250 IBO, Flanged, Energy-Efficient, 600W

Product detailed description

The IBO NOVA 25-60/180 circulation pump is equipped with a permanent magnet motor and a differential pressure controller, which automatically and continuously adjust the pump's output to match the actual needs of the system.  The pump's control panel is located on the top of the motor, making it easier for the user to operate. Current electricity consumption is shown on its display. The pump unit includes a set of screw connections with an adapter for cable connection. Energy-efficient electric circulation pumps that meet the requirements of energy class A pumps. The energy efficiency index of the  NOVA  series pumps is:  EEI <= 0.2 , which, according to Commission Regulation (EU) No. 622/2012 is the reference criterion for:  the most energy-efficient circulation pumps. The IBO NOVA 25-60/180 circulation pump is suitable for: heating systems with constant temperature and variable flow heating systems with variable pipe temperature heating systems with night mode air conditioning systems industrial circulation systems domestic central heating systems domestic hot water systems Technical parameters: Maximum flow rate:      55 l/min Maximum head:      6 m Motor power:      0.05–0.45 kW Overall length:      180 mm Connection thread:      6/4"
