Karma SOLAR 25 FC

Code: NC-12652

Not rated Rating details

Brand: KARMA

1 882,40 € –29 %

1 882,40 € –29 % 1 318 € / pcs

The item has been sold out…

Detailed information

Product detailed description

Karma SOLAR 25 FC - gas condensing boiler for solar systems for heating and DHW heating

Wall-mounted gas condensing boilers, compared to conventional boilers, additionally make use of the heat contained in the flue gases. Thanks to this system, condensing boilers have about 15% higher efficiency and roughly up to 25% lower gas consumption compared to classic boilers. Using condensing boilers together with or with a large radiator heating surface is very advantageous.

Wall-mounted gas condensing Karma Solar series boilers are intended for heating (CH) family houses, flats, etc. and for heating domestic hot water (DHW) - provided via a plate . The Solar boiler is designed for connection to a system with solar panels and a storage tank. Another heat source, e.g. a wood boiler from the Forest series, can also be connected into the system. Heat is drawn from the storage tank heated by the solar panel for heating DHW and heating water. Only when there are increased demands on the temperature and quantity of DHW, or under unfavourable weather conditions, is the additional heating of DHW ensured by the boiler. This results in a significant reduction in gas consumption.

Technical parameters:

Dimensions (h x w x d): 880 x 450 x 360 mm
Weight: 47 kg
Input: 10.5 - 25 kW
Flue gas discharge: Turbo
Sealed combustion chamber - air intake and flue gas discharge outside the room
Primarily copper heat exchanger
Electronic burner flame modulation
Practical control panel with buttons and a display showing current values
WINTER - SUMMER function for CH and DHW
Option to connect an outdoor sensor for weather-compensated control, the boiler then heats the heating water depending on the outdoor temperature
Precise control of domestic hot water temperature setting, precise control of heating water temperature, thermometer and pressure gauge of heating water
Safety valve - 3 bar, expansion vessel with a volume of 7.5 l
