Dražice OKCE 100
Code: 1108108101Related products
Product detailed description
Round electric water heater, boiler Dražice OKCE 100 for water heating, designed for wall mounting
Application:
- Electric accumulation wall-mounted vertical boiler designed for multiple points of use for heating water with electric energy
- Suitable as a source of hot water for family houses, apartments, accommodation facilities, and places with a need for a larger amount of hot water
- Possibility of hot water preparation using a lower electricity tariff - night current
- Suitable for a family of two or more members
- Suitable for damp environments
- Vertical installation on the wall - upright
- Wide range of use
Features and advantages:
- The materials and components used guarantee long-lasting durability and safe comfort
- Attractive design
- Possibility of using a low electricity tariff - night current
- Ceramic heating element controlled by an operating thermostat
- Enamelled tank
- Combination of high performance and low energy consumption
- Low heat losses
- Resistant to corrosion and limescale buildup
- Safety valve
- Operating thermostat
- Safety thermostat - thermal fuse
- Thermometer
- Magnesium anode, 65 mm polyurethane insulation
Product tested according to the highest quality standards
Accessories - safety valve
| Type | OKCE 50 | OKCE 80 | OKCE 100 | OKCE 125 | OKCE 160 | OKCE 200 |
|---|---|---|---|---|---|---|
| Volume [l] | 50 | 80 | 100 | 125 | 160 | 200 |
| Maximum operating pressure of the tank [MPa] | 0.6 | 0.6 | 0.6 | 0.6 | 0.6 | 0.6 |
| Voltage [V] | 230 | 230 | 230 | 230 | 230 | 230 |
| Power input [W] | 2 000 | 2 000 | 2 000 | 2 000 | 2 000 | 2 200 |
| Electrical protection | IP 45 | IP 45 | IP 45 | IP 45 | IP 45 | IP 45 |
| Heater height [mm] | 561 | 736 | 881 | 1 046 | 1 235 | 1 300 |
| Heater diameter [mm] | 524 | 524 | 524 | 524 | 524 | 584 |
| Maximum weight of heater without water [kg] | 30 | 36 | 42 | 48 | 58 | 76 |
| Heating time from 10° to 60°C | 1.5 hrs. | 2.5 hrs. | 3 hrs. | 3.5 hrs. | 5 hrs. | 5.5 hrs. |
Frequently Asked Questions
- What tank volume should I choose? A common estimate of consumption is based on approx. 40-50 liters of hot water (at approx. 40-45 °C) per person per day for standard use (showering, washing); for bathing in a tub or a larger number of bathrooms/outlet points, a larger volume should be considered. When choosing, also consider whether the tank will be heated by a boiler with high output (faster heating, a smaller volume may be sufficient) or, for example, only by a solar system (where, on the contrary, a larger volume is worthwhile for accumulating heat during the day).
- Can I connect this DRAŽICE tank to an existing boiler? In most cases, yes, but you should check the compatibility of the hydraulic connection (dimensions and type of connections) and whether your boiler supports control of the tank heating (a temperature sensor in the tank and possibly a switching valve are needed) - you can find these details in the product's technical parameters, or our customer service will advise you.
- Where and how is the tank placed? The tank is placed as close as possible to the heat source (boiler) to minimize heat losses in the connecting piping, but with sufficient space around it for service access (anode replacement, safety valve inspection).
- Must the installation be done by a professional? We always recommend entrusting the hydraulic connection to the water supply and the heat source, including installation of the safety valve at the correct pressure, to a heating engineer/plumber - an incorrectly installed or missing safety valve poses a safety risk.
Additional parameters
| Category: | electric round water heaters - OKCE |
|---|---|
| Warranty: | 2 years |
| Weight: | 42 kg |
| Magnesium anode: | 65 mm |
