Dražice OKCE 180
Code: 110410801Related products
Product detailed description
Electric round water heater, boiler Dražice OKCE 180
Working position – vertical (wall-mounted)
Optional equipment:
- Circulation inlet
- Heating element with an output of 4 kW and connection 3 PE-N 400 V/50 Hz (included in the price for 72.99 EUR with VAT)
Main use:
- Preparation of domestic hot water in buildings with the possibility of using a low electricity tariff (night current).
Accessories:
- Safety valve
Electric storage water heaters designed for wall mounting with volumes of 50–200 liters. The manufacturer maintains the spacing of the mounting screws throughout the entire production history to make it easier to replace old water heaters. It is also possible to purchase a bracket for a mounting screw spacing of 350 mm.
Heating is provided by a ceramic heating element controlled by an operating thermostat and protected by a safety thermostat (thermal fuse). Temperature range 5–74 °C. Connection voltage 1-PE–N/AC 230 V/50 Hz. Electrical protection IP 45 allows the water heater to be placed in zone 1 according to ČSN 33 2000–7–701.
| Type | OKCE 50 | OKCE 80 | OKCE 100 | OKCE 125 | OKCE 160 | OKCE 180 | OKCE 200 |
|---|---|---|---|---|---|---|---|
| Volume [l] | 51 | 80 | 100 | 125 | 152 | 180 | 200 |
| Maximum operating pressure of the tank [MPa] | 0.6 | 0.6 | 0.6 | 0.6 | 0.6 | 0.6 | 0.6 |
| Voltage [V] | 230 | 230 | 230 | 230 | 230 | 230 | 230 |
| Power input [W] | 2 000 | 2 000 | 2 000 | 2 000 | 2 000 | 2 200 | 2 200 |
| Electrical protection | IP 45 | IP 45 | IP 45 | IP 45 | IP 45 | IP 45 | IP 45 |
| Water heater height [mm] | 561 | 736 | 881 | 1 046 | 1 235 | 1 200 | 1 300 |
| Water heater diameter [mm] | 524 | 524 | 524 | 524 | 524 | 584 | 584 |
| Maximum weight of water heater without water [kg] | 30 | 36 | 42 | 48 | 58 | 72 | 76 |
| Heating time with electric energy from 10 °C to 60 °C [hours] | 1.5 | 2.5 | 3 | 3.8 | 5 | 5 | 5.5 |
| Heat losses/energy efficiency class [kWh/24 hours] | 0.45/C | 0.71/C | 0.88/C | 1.09/C | 1.39/C | 1.39/C |
1.4/B |
Additional parameters
| Category: | electric round water heaters - OKCE |
|---|---|
| Warranty: | 2 years |
| Product replaced by new one: | https://www.atria.sk/quadroflex-bch-120/ |
| The item has been sold out… | |
