Dražice OKCE 80
Code: 1101108101Related products
Product detailed description
Electric round water heater, boiler Dražice OKCE 80 for water heating, designed for wall mounting
Use:
- Electric storage wall-mounted vertical water heater intended for multiple draw-off points for heating water with electric energy
- Suitable as a source of hot water for family houses, apartments, accommodation facilities, and places with a need for a larger amount of hot water.
- Possibility of preparing hot water using a lower electricity tariff - night current
- Suitable for a family of two or more members
- Suitable for damp environments
- Vertical installation on the wall - upright
- Wide range of use
Features and advantages:
- The materials and components used guarantee a long service life and safe comfort
- Attractive design
- Possibility of using a low electricity tariff - night current
- Ceramic heating element controlled by an operating thermostat
- Enamelled tank
- Combination of high output and low energy consumption
- Low heat losses
- Resistant to corrosion and limescale build-up
- Safety valve
- Operating thermostat
- Safety thermostat - thermal fuse
- Thermometer
- Magnesium anode, 65 mm polyurethane insulation
Product tested according to the highest quality standards
Accessories - safety valve
| Type | OKCE 50 | OKCE 80 | OKCE 100 | OKCE 125 | OKCE 160 | OKCE 200 |
|---|---|---|---|---|---|---|
| Volume [l] | 50 | 80 | 100 | 125 | 160 | 200 |
| Maximum operating pressure of the vessel [MPa] | 0.6 | 0.6 | 0.6 | 0.6 | 0.6 | 0.6 |
| Voltage [V] | 230 | 230 | 230 | 230 | 230 | 230 |
| Input power [W] | 2 000 | 2 000 | 2 000 | 2 000 | 2 000 | 2 200 |
| Electrical protection | IP 45 | IP 45 | IP 45 | IP 45 | IP 45 | IP 45 |
| Heater height [mm] | 561 | 736 | 881 | 1 046 | 1 235 | 1 300 |
| Heater diameter [mm] | 524 | 524 | 524 | 524 | 524 | 584 |
| Maximum heater weight without water [kg] | 30 | 36 | 42 | 48 | 58 | 76 |
| Heating time from 10° to 60°C | 1.5 hrs | 2.5 hrs | 3 hrs | 3.5 hrs | 5 hrs | 5.5 hrs |
Frequently Asked Questions
- What tank volume should I choose? A common estimate of consumption is based on approximately 40-50 liters of hot water (at approx. 40-45 °C) per person per day for standard use (showering, washing); for bathing in a tub or a higher number of bathrooms/draw-off points, a larger volume should be considered. When choosing, also take into account whether the tank will be heated by a boiler with high output (faster heating, a smaller volume may be sufficient) or, for example, only by a solar system (where, on the contrary, a larger volume is worthwhile for accumulating heat during the day).
- Can I connect this DRAŽICE tank to an existing boiler? In most cases, yes, but you should check the compatibility of the hydraulic connection (dimensions and type of connections) and whether your boiler supports control of the tank heating (a temperature sensor in the tank and possibly a switching valve are required) - you can find these details in the product's technical parameters or ask our customer service for advice.
- Where and how is the tank placed? The tank is placed as close as possible to the heat source (boiler) to minimize heat losses in the connecting pipework, while still leaving enough space around it for service access (anode replacement, safety valve inspection).
- Must the installation be done by a professional? We always recommend entrusting the hydraulic connection to the water supply and to the heat source, including fitting the safety valve at the correct pressure, to a heating engineer/plumber - an incorrectly fitted or missing safety valve represents a safety risk.
Additional parameters
| Category: | electric round water heaters - OKCE |
|---|---|
| Warranty: | 2 years |
| Weight: | 36 kg |
| Magnesium anode: | 65 mm |
