Karma BETA 2E 01

Code: BETA 2E 01

Not rated Rating details

Brand: KARMA

936,89 € –3 %

936,89 € –3 % 908,77 € / pcs

1 week

Detailed information

Product detailed description

Karma Beta 2 Electronic 01

Gas stove with an output of 2 kW with flue gas discharge through the wall and very easy operation. The set temperature is maintained automatically. The stove is fitted with an electronic control system that ignites the burner, regulates the gas supply, and monitors the flame as well as all functions affecting the operation and safety of the stove. Thanks to electronic regulation, gas savings of up to 25% can be achieved compared to the BETA Mechanic. In standby mode the Beta Electronic has ZERO gas consumption, unlike the Beta Mechanic it has no permanent pilot flame. The stove has its own switching clock and can also be connected to a suitable room thermostat - more than one stove can be connected to a single thermostat.

The stove is resistant to sub-zero temperatures.

Advantages:

stove output 2 kW
suitable for rooms up to 40 m³
automatic maintenance of room temperature without the need for further operation
electronic temperature regulation in the range 0 to 40°C
built-in adjustable switching clock, adjustable within a 24-hour range
frost resistance of the stove
high stove efficiency (higher than heating systems with a boiler)
independence of the stove
high operating safety
gas-tight combustion chamber made of steel sheet
combustion chamber walls enamelled on both sides
stainless steel gas burner
gas valve SIT 630 EUROSIT
wall-mounted installation
combustion circuit gas-tightly separated from the room environment
combustion air is drawn in from the outside
flue gas is discharged through the outer wall via an opening with a diameter of 122 mm
stove casing made of steel sheet protected by special powder coating
maximum wall thickness 82 cm
factory setting for natural gas
can be converted for propane-butane
24-month warranty
the flue outlet part cannot be placed on sloped roofs
fixing material and parts for hanging the stove on the wall
outer cover basket
complete flue outlet assembly
wall flue outlet pipes, length 60 cm (a length of up to 82 cm can be ordered)

Dimensions:

A = 416 mm
B = 267 mm
C = 188 mm

Technical data	Karma Beta 2 Electronic 01
Output (kW)	2
Colour	ochre, brown, white
Weight (kg)	15
Colour of grilles on the heating body	black
Colour of outer basket	unpainted aluminium
Temperature selector	0 to 40 °C
Electrical connection / power input	230 V/9.4 W
Gas connection	G 1/2
Efficiency (%)	87%
Outer dimensions	416 x 215 x 600
Consumption - natural gas (m3 / h)	0.24
Consumption - propane butane (m3 / h)	0.18
Centre of flue outlet from left edge (mm)	149
Diameter of wall flue outlet (mm)	122

Note:

Price shown without the flue outlet (can be ordered separately):

Wall flue outlet 60 cm - VYD60
Wall flue outlet 82 cm - VYD82

Frequently Asked Questions

How do I choose the right output for a KARMA electric boiler? As with gas boilers, base your choice on the calculated heat loss of the building to be heated. For electric boilers it is also crucial to check whether the capacity of your electrical connection to the house (flat) allows it - higher outputs (from roughly 12 kW upwards) usually require a three-phase 400 V connection and a correspondingly sized main circuit breaker, which will be confirmed by a revision technician or directly by the electricity distributor.
Is an electric boiler worth it compared to a gas or solid-fuel boiler? An electric boiler has the lowest purchase price and the simplest installation (no flue gas extraction is needed, since it burns nothing), but operating costs for electricity are usually higher than for gas or wood/coal for the same amount of heat delivered. It is particularly suitable where gas is not available, as a supplementary/backup source, or for a building with low consumption (well-insulated new builds, cottages, flats).
How does an electric boiler regulate output? Most models switch individual heating elements on/off gradually (in stages); some more modern models also allow smoother output modulation - this affects the smoothness of heating and, to some extent, the service life of the switching components.
Can I install this electric boiler myself? Connection to the electrical network, inspection and commissioning must be carried out by a person with electrotechnical qualification in accordance with the applicable standard STN 33 2000 and related regulations - DIY installation is not permitted, either for warranty or safety reasons.
Can this electric boiler also heat domestic hot water? For many models, yes, usually in combination with a separate domestic hot water tank and a switching (3-way) valve, which switches between the heating circuit and heating the tank - the exact possibility and required accessories for this particular model can be found in the technical parameters above, or consult our customer service.

Additional parameters

Category:	Beta Electric
Warranty:	2 years
Weight:	10 kg
Flue outlet through wall:	60 cm
Maximum wall thickness:	82 cm
Stove heat output:	2 kW
Wall Flue Pipes Length:	60 cm
