Q-TERMO TMBSPDL 144
Code: TMBSPDL144Related products
Product detailed description
Product description
Q-TERMO TMBSPDL 144
- SET - non-pressurised instantaneous water heater TM 144 + standing lever mixer tap
- designed for a single outlet - output: 4.4 kW
Features:
- Robust construction of the unit guarantees trouble-free operation even under demanding operating conditions.
- Non-pressurised electric heater, must only be installed with a non-pressurised (three-way) mixer tap.
- For a single outlet.
- Two robust heating elements in each unit significantly reduce the risk of damage to the unit from air pockets or limescale build-up.
- Hydraulically controlled switching, via an elastomer diaphragm and precision microswitches.
- Instant heating of flowing water, with a heating indicator.
- Designed for top or bottom installation for a single outlet.
Dimensions
| Parameters | TM 144 | |||
|---|---|---|---|---|
| Total output of heating elements (kW) | 4.4 | |||
| Power supply (V/Hz) | 1/N/PE ~ 230/50 | |||
| Fuse rating (A) | 20 | |||
| Minimum permissible water pressure (MPa) | 0.2 | |||
| Maximum permissible water pressure (MPa) | 0.6 | |||
| Flow rate at water heating Δ t = 30 °C (l/min) | 2.1 | |||
| Water connection (G") | 3/8" | |||
| Electrical protection rating | IP 25 | |||
| External dimensions w x h x d (mm) | 136/200/65 | |||
| Weight (kg) | 1.5 | |||
| Energy class | A | |||
Additional parameters
| Category: | Non-Pressurized |
|---|---|
| Warranty: | 2 years |
| Weight: | 10 kg |
| The item has been sold out… | |
