Ladomat 65 °C for Solid Fuel Boilers, Wood, Coal, Pellets - Without Check Valve
Code: 4925SProduct detailed description
Ladomat 65 °C for solid fuel boilers, wood, coal, pellets - without check valve
- prefabricated, automated, thermally controlled circulation unit for solid fuel boilers and heating;
- the TERMOVAR circulation unit controls the minimum temperature of the medium entering the boiler and increases its efficiency, prevents fouling and substantially extends the service life of the solid fuel boiler;
- eliminates the risk of thermal shocks caused by the inflow of cold water;
- ensures more efficient combustion of solid fuels, and is therefore a necessary part of the heating system with a storage tank.
- Voltage: 230 VAC 50/60 Hz
- Power input: 45 VA
- Max. boiler capacity: 80 kW
- Max. operating temperature: 110°C
- Max. operating pressure: PN 6
- Opening temperatures 45°C, 55°C, 61°C, 72°C or 80°C
- Pump UPS 25-60
- Connection sizes: RP 1", RP 5/4" and 28 mm
- Unit dimensions: 210 x 210 x 110 mm
- Weight: 5,0 kg
Included in delivery:
- Thermally controlled filling valve
- Backflow protection
- Thermoregulatory pump
- Three thermometers
- Three ball valves
Additional parameters
| Category: | Ladomat controllers, controls |
|---|---|
| Warranty: | 2 years |
| Weight: | 5 kg |
| The item has been sold out… | |
Product rating
Be the first who will post an article to this item!
Discussion
List of discussions
P
pavol
pavol
Dobry den aky by som mal pouzit ladomat na kotol na spiatocku a akumulacnu nadz? bez klapky ci z klapkov ci prefabrikofana klapka??
A
atria
atria
Dobrý deň. Žiaľ, ale toto sa nedá jednoducho napísať . To záleží na zapojení, na regulácií a na ďalších veciach. Prajem pekný deň.
