SALUS 11M

Product detailed description

SALUS Thermostat EUROTEMP 11M for controlling a three-way valve in the boiler circuit for solid fuel boilers (wood, coal, pellets and others)

• Controls the three-way valve in the boiler circuit and ensures a constantly warm return water flow back to the boiler
• Prevents boiler corrosion
• Switches the boiler on and off according to the room thermostat
• Sets the outlet water temperature for the heating system

The EUROTEMP 11M is a modern, processor-controlled thermostat with a backlit graphic display and simple operation. The thermostat intelligently controls the functions of the heating system with a three-way valve.

In heating systems with boilers, the EUROTEMP 11M device controls the valve function and keeps the temperature of the return water at the required level. With correct settings, condensation on the boiler surface during water heating is prevented, which significantly extends the boiler's service life. The thermostat's temperature sensor measures the current temperature of the return water in the pipe leading into the boiler.

The EUROTEMP 11M thermostat features an Antystop system, which protects the pump from seizing or fouling. Outside the heating season, the EUROTEMP 11M thermostat's processor runs the pump for 30 seconds every 14 days. For the Antystop function to work, the thermostat must not be switched off outside the heating season.

USE

• Controls the three-way valve of the heating system

TECHNICAL SPECIFICATION:

• Temperature control range: 10-70 °C
• Temperature measurement range: 0-110 °C
• Hysteresis: 2 °C
• Max. current: 3A AC
• Supply voltage: 230V AC
• Number of sensors: 2x
• Clamp-on sensor: 1.5 m (if you need a longer sensor, please contact us at the details provided)
