Saswell KIT TRV 4 + 1 - smart system for radiators

Product detailed description

Saswell KIT TRV 4 + 1 - wifi heating system for radiators

- a stylish, precise and programmable TRV controller designed for independent control of radiators.

A set for controlling radiator heating via an app for Android and iOS.

The system can be expanded from the four supplied smart heads up to 10.

Technical parameters:

Gateway:

• power supply: adapter 220V - DC 5 1V 2A,
• IP rating: IP21,
• ambient temperature: 0-50°C,
• storage temperature: -10°C to 60°C,
• RF connection, frequency: 868 MHz, FSK,
• range: up to 100 m in open space,
• WIFI protocol: TCP/IP, MQTT,
• WIFI frequency: 2412 GHz - 2484 GHz
• Connection limit: up to 10 heads, 1 receiver,
• dimensions: h/w/d: 80 mm/125 mm/26 mm

Receiver:

• power supply: 100-240 V AC, 50/60 Hz,
• IP rating: IP21,
• ambient temperature: 0-50°C,
• storage temperature: -10°C to 60°C,
• output/contacts: 1 x boiler, lmax 250 VAC 10(6) A, 1 x electrical contact 220 VAC (e.g. pump) lmax 250 VAC 10(6)A
• RF connection, frequency: 858 MHz, FSK,
• range: up to 100 m in open space,
• dimensions: h/w/d: 86 mm/86 mm/24 mm.

Smart thermostat for radiator heads:

• power supply: 2 AA alkaline batteries LR06 (do not use rechargeable batteries!),
• battery life: up to 1 year,
• adjustable temperature: from 5°C to 30°C,
• adjustment in steps of: 0.5 °C,
• displayed temperature range: 0°C - 50°C, accuracy: 0.1
• ambient temperature: 0°C - 50°C,
• storage temperature: -10°C to 60 °C,
• RF frequency: 868 MHz, FSK,
• RF range: up to 100 m in open space,
• dimensions: h/w: 88.6 mm/50 mm
