Thermoregulatory bypass valve - 6/4"; Kv 17; 45° C
Code: 1680000Related products
Product detailed description
Thermoregulatory bypass valve, IVAR.TERMOVAR, size: 6/4", temperature: 45 °C, Kv 17
- PN 10, T = +120 °C
- protects solid-fuel boilers against low-temperature corrosion and tar deposits
- replaceable thermostatic cartridge
- material: cast iron
Note: The operating flow rate can be adjusted under pressure without tools.
Frequently asked questions
- How do I choose the correct type and size of fitting/valve? Follow the nominal pressure (PN) and operating temperature (T) stated in the technical parameters - they must match or exceed the actual operating conditions of your system, and the connection size must match the pipe diameter.
- How does this fitting/valve work? The exact operating principle (shutting off, pressure regulation, non-return function, etc.) depends on the specific type - a detailed description of the function can be found above for this product.
- Must installation be done by a professional? Simple shut-off fittings can be installed by a competent DIYer; for control and safety fittings (safety valves, pressure-reducing valves) we always recommend a professional, as these are safety-critical components.
Additional parameters
| Category: | thermoreg. bypass valves |
|---|---|
| Warranty: | 2 years |
| Weight: | 2.982 kg |
| Material type: | cast iron Note |
| Operating temperature: | +120 °C |
| Nominal pressure: | PN 10 |
| Last price update: | 13.04.2026 1:12:26 |
